Keychron V5 Knob version is a fully customized 96% layout mechanical keyboard packed with all premium features and unlimited possibilities. V5 is an all-plastic keyboard that allows customizable capabilities for every key switch, keycap, knob, and stabilizer. It’s made for your personalized experience and a more comfortable typing experience.
ColorNon-Knob Barebone ANSI Frosted BlackNon-Knob ANSI Barebone Carbon BlackKnob ANSI Barebone Carbon Black
Compatible BundlesKeychron V5 Bundle
Keychron V5 Mechanical Keyboard
ISO layout is widely used in Europe while the ANSI layout is widely used by the rest of the world. If you live in Europe, we recommend you to purchase the "Barebone ISO” version with the corresponding ISO Dye-sub PBT keycap sets together. The "Barebone ISO” is suitable for all ISO keyboard countries like the UK, Germany, France, Italy, Spain, Denmark, Norway, Sweden, Finland, Iceland, etc.
The hot-swappable sockets are mounted on the PCB, so you can install or change the switches without soldering. The PCB supports both 3 pin and 5 pin MX mechanical switches.
The south-facing RGB is designed to better illuminate the keyboard backlight from the typist’s angle with the premium non-shine-through PBT keycaps installed. The south-facing RGB is also free from interference when the user installs Cherry-profile alternative keycaps on their keyboard.
PS: Changing the knob with a badge or key requires an additional PCB (sold separately).
18.85 mm (without keycaps)
26.43 mm (without keycaps)
3.5° / 7.20° / 9.73°
1170 g ± 10 g (Fully Assembled version)
Tray Mount Design
Double-shot PBT keycaps, not shine-through, OSA Profile (OEM height, SA shape)
Ultra-low-power Arm Cortex-M4 32-bit STM32L432 (128KB Flash)
South-facing RGB LED
Gateron Red G Pro (Fully Assembled version)
Hot-swappable (5 pin & 3 pin)
Screw-in PCB stabiliser
Type-C cable + Type-A to Type-C adapter
Learn more about the Keychron V5 such as the V5 shortcuts, assembling the V5, factory reset, and more in the FAQ section.
Compatible keycaps, plates and accessories for the Keychron V5
